A simple, reliable solar charge controller designed for caravans, camper trailers, 4WDs, RVs, boats and off-grid power systems. The Victron PWM range provides dependable battery charging, battery protection and load control in an easy-to-use package featuring a clear LCD display, programmable settings and dual USB charging ports.

Available in 5A, 10A, 20A and 30A models, there's an option to suit everything from compact solar setups through to larger touring and camping systems.

Which Model Is Right For You?

5A – Ideal for small solar systems powering auxiliary batteries, maintenance charging, lighting circuits or low-current applications.

10A – Suits smaller 12V touring setups running camp lighting, communications equipment and compact fridges.

20A – A popular choice for medium-sized caravan, camper trailer and canopy systems with moderate solar input and accessory loads.

30A – Designed for larger off-grid systems requiring higher charging capacity and greater load management.

Select your preferred amperage from the dropdown menu above to match your solar panel output and battery system requirements.

Clear LCD Display

The integrated LCD screen provides real-time visibility of charging status, battery voltage and load information, making it easy to monitor system performance and adjust settings when required.

Adjustable Load Output Protection

The programmable load output helps protect your battery from excessive discharge by automatically disconnecting connected loads when battery voltage reaches a preset threshold.

Load reconnect and disconnect voltages can be customised to suit your battery type and application.

For high-current devices such as inverters, direct battery connection is recommended, with the inverter remote trigger connected via the controller's load output if required.

Programmable Day & Night Timer Function

Built-in timing functions allow loads such as camp lights or auxiliary accessories to automatically switch on after sunset for a user-defined period.

This feature is particularly useful for camping, remote installations and unattended lighting applications.

Battery Compatibility

Pre-configured charging profiles are available for:

• AGM Batteries

• GEL Batteries

• Flooded Lead Acid Batteries

• LiFePO₄ Batteries (with internal BMS)

Selectable charge algorithms help maximise charging efficiency while supporting long battery life.

Dual USB Charging Ports

Dual 5V USB outputs provide convenient charging for phones, GPS units, lighting and other low-power devices.

Maximum combined USB output: 2A.

Proven PWM Charging Technology

Victron PWM Solar Charge Controllers are designed for systems where solar panel voltage closely matches battery charging voltage.

Pulse Width Modulation (PWM) technology delivers reliable charge regulation by maintaining appropriate charging voltages, preventing overcharging and supporting long-term battery health.

For systems where solar panel voltage is significantly higher than battery voltage, such as 24V panels charging 12V batteries, a Victron MPPT controller will provide improved charging efficiency and energy harvest.

Key Features

• Available in 5A, 10A, 20A and 30A models

• Suitable for 12V and 24V battery systems

• LCD display for system monitoring and configuration

• Programmable load output with battery protection

• Adjustable day/night timer functionality

• AGM, GEL, Flooded and LiFePO₄ battery compatibility

• Dual USB charging outputs

• Reliable PWM charging technology

• Compact and easy to install

• Backed by a 5-year Victron warranty

Specifications

Additional specifications are shown in the product images.
